Protein Powder Filling Machine,Jar Filling Machine

Group automatic powder filling machine
PriceUS $6000 / piece
Min. Order 1 piece
Terms of Payment L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Update Time 2018-12-10
Item specifics
Size of the containerCylindrical container 50-160MM High 50-350MM
Packing weight1-6000g
Packaging accuracy≤1%
Filling rate20-50 cans/min
Power supply3P 380V/1P 220V
Air pressure6-8kg/ cm2
Use tolerance0.2m3 /min
Total weight450kg
Description

Product Description


Mode: DCS-2B Powder Packaging Machine

Introduction and Brief

This newest model of DCS-2B spice powder filling machine was designed based on our long-range experience accumulation, in terms of the National GMP Standard. The DCS-2B spice powder filling machine can feeding, weighing, filling and failure pack detecting & deleting automatically.Our DCS-2B spice powder filling machine is suitable for packaging powdery & grainy product, for instance, milk powder, rice powder, monosodium glutamate, solid beverage, dextrose, etc.

Characteristics

1. Stainless steel material except of motor, in particular the application of GMP, food sanitation certification, and suitable for the amyctic materials.
2. Touch-screen man-machine interface: work stability, anti-interference, high-precision weighing, easy and intuitive to operate.
3. Stepless adjust the packaging weight.
4. Change the working parameter at any time, easy to control.
5. Servo motor driving screw is characteristics of high-precision orientation, high-speed, great-torque, long-life, setup rotate speed, stable performance.
6. Stirrer’s driven by the Taiwanese motor reducer: low noise, long life, maintenance-free life.
7. Weight feedback and proportion track get rid of the shortage of variable packaged weight for various proportion of different material
8. Side-open of the hopper is made of stainless steel and is consist of glass,damp. material movement at a glance through the glass,air-sealed to avoid the leak, and the discharge material mouth with the dust collector to protect the workshop dnvironment .
9. Replacing the auger parts, it is suitable for material from super thin powder to granule.

Technical Parameters

Model
DCS-2B Spice Powder Filling Machine
Metering mode
Auger rotation filling
Size of the container
Cylindrical containerφ50-160MM High 50-350MM
Packing weight
1-6000g
Packaging accuracy
≤1%
Filling rate
20-50 cans/min
Power supply
3P 380V/1P 220V
Total power
2KW
Air pressure
6-8kg/ cm2
Use tolerance
 0.2m3 /min
Total weight
450kg
Overall Dimensions
2500×1250×2300MM
Hopper volume
50L


Certification



Packing for  5 Litter Automatic Lubricant Oil Filling Machine Line

Standard Export Packing for vegetable cooking oil filling machine

A.Cover by PVC film + fumigated wooden case;

B.Wooden case suitable for long distance ocean shipping.




In addition, you could also purchase other related products and premium package online.For example:1. Filling Machine + Packaging Machine + Coding Machine + Labeling machine+ Wrapping machine + Sealing machine2. Filling Production Line3. Filling Machine + Coding Machine + Labeling machine+ Wrapping machine
If you still have any questions about this machine, please don't hesitate to contact us and list your needs and demands. we will reply to you asap.Thank you and welcome to JINAN DONGTAI.
